APDD 739
June 1999
XF 20 - 30
EP 20 - 30
HP 20 - 30
HXP 20 - 30
OPERATORS/
INSTRUCTION MANUAL
OPTIONS
Before installation or starting the compressor for
the first time, this manual should be studied careful-
ly to obtain a clear knowledge of the unit and of the
duties to be performed while operating and main-
taining the unit.
RETAIN THIS MANUAL WITH UNIT.
This Technical manual contains IMPORTANT SAFE-
TY DATA and should be kept with the air compres-

Table of Contents

Questions and Answers

  • B
    Brian SmithAug 14, 2025
    What to do if Ingersoll-Rand Air Compressor fails to start?
    • C
      christycombsAug 14, 2025
      If your Ingersoll-Rand Air Compressor fails to start, there are several potential causes and solutions: * Check the fuses, transformers, and wiring connections to ensure that 110/120V control voltage is available. * Inspect the contactors in case of a "STARTER FAULT". * If there is an "EMERGENCY STOP" message, rotate the emergency stop button to disengage it and press the "SET" button twice. * If the message is "MAIN MTR OVER LD", manually reset the main overload relay and press the "SET" button twice. * For "PRES SENSOR FAIL", "TEMP SENSOR FAIL", or "NO CONTROL POWER" messages, check for a defective sensor, a bad sensor connection, or broken sensor wires.
  • J
    justin56Aug 18, 2025
    Why does my Ingersoll-Rand Air Compressor shut down?
    • V
      vhowellAug 18, 2025
      Your Ingersoll-Rand Air Compressor might shut down due to several reasons: * If there is a "HIGH AIREND TEMP." message, ensure the installation area has adequate ventilation. * For a "HIGH AIR PRESS." message, make sure the cooling fan is operating. If not, reset the circuit breaker inside the starter box. * If the message is "LOW SUMP PRESS.", check the coolant level and add coolant if needed. * In case of "PRES SENSOR FAIL" or "TEMP SENSOR FAIL", check for a defective sensor, a bad sensor connection, or broken sensor wires.
  • B
    brittany22Aug 21, 2025
    What causes low system air pressure in Ingersoll-Rand EP 30?
    • A
      Anthony GreeneAug 21, 2025
      Low system air pressure in your Ingersoll-Rand Air Compressor can be caused by: * The compressor running in "Unload" Mode - press the "UNLOAD/LOAD" button. * The controller off-line set point being too low - press the "UNLOAD/STOP" button and set the off-line set point at a higher value. * A dirty air filter element - check the filter condition and replace it as required.
  • R
    Roy GreenAug 25, 2025
    What to do if Ingersoll-Rand Air Compressor has high coolant consumption or coolant in air system?
    • J
      Jackie ShahAug 26, 2025
      If your Ingersoll-Rand Air Compressor is experiencing high coolant consumption or has coolant in the air system: * Check the coolant level and lower it by draining if it's excessive. * Check the separator pressure drop, as a plugged separator element could be the cause. * Inspect the coolant system for leaks and repair them.
  • J
    jwoodsAug 28, 2025
    How to reduce excessive noise level of Ingersoll-Rand EP 30 Air Compressor?
    • C
      Cynthia KellyAug 28, 2025
      To address an excessive noise level in your Ingersoll-Rand Air Compressor: * Inspect the moisture separator/drain trap and clean it if required. Replace the separator/trap if it is defective. * Inspect and clean the aftercooler core if it's dirty.
  • C
    Charlene OsborneAug 31, 2025
    What causes black residue on belt guards of Ingersoll-Rand Air Compressor?
    • K
      kristenallenAug 31, 2025
      Black residue on the belt guards of your Ingersoll-Rand Air Compressor is typically caused by: * Loose V-belts - adjust the belt tension. * Misaligned sheaves - align the sheaves.
  • L
    Laura FullerSep 3, 2025
    What causes excessive vibration in Ingersoll-Rand Air Compressor?
    • C
      Cynthia GoodwinSep 4, 2025
      Excessive vibration in your Ingersoll-Rand Air Compressor can be due to: * Loose components - inspect and tighten them. * Motor or compressor bearing failure - contact an authorized Distributor or Air Center immediately and do not operate the unit.
  • R
    Rodney Mata DVMSep 7, 2025
    What causes Pressure relief valve to open on Ingersoll-Rand EP 30 Air Compressor?
    • T
      Terry WardSep 7, 2025
      The pressure relief valve on your Ingersoll-Rand Air Compressor may open if the compressor is operating over pressure. Adjust the Intellisys setpoints to resolve this issue.
  • B
    Bernard ParkerSep 12, 2025
    What causes Shaft Seal leak in Ingersoll-Rand EP 30 Air Compressor?
    • R
      ryan10Sep 12, 2025
      A shaft seal leak in your Ingersoll-Rand Air Compressor is caused by a defective shaft seal. Replace it according to the manual or contact an authorized Distributor or Air Center.

Summary

Warranty Information

Bonded Warranty and Registered Start Up

Standard warranty terms for equipment, covering defects in material and workmanship.

Extended Airend Warranty

Specific warranty for the airend component when using ULTRA COOLANT.

Safety and Warnings

General Safety Instructions

General guidelines for safe operation and maintenance of the compressor.

Key Safety Precautions

Crucial safety steps to follow before installation or maintenance.

Safety Shutdown Procedures

Procedure to test the high discharge air temperature shutdown function.

Installation Procedures

Ventilation Requirements

Requirements for adequate ventilation around the compressor to prevent overheating.

Foundation and Mounting

Piping Guidelines

Electrical Installation and Wiring

Steps for connecting incoming power and ensuring electrical safety.

Voltage Conversion

Rotation Check

How to check and correct motor and fan rotation direction.

Starting and Stopping Procedures

Procedures for safely starting, operating, and shutting down the compressor.

Outdoor Sheltered Installation

Compressor Systems Overview

General System Description

Coolant System Functionality

Air System Components and Flow

Electrical System Overview

Capacity Control Modes

Pressure Switch Adjustment

Procedure for adjusting the compressor's operating pressure switches.

Modulation and ACS Control

Modulate Control Valve Adjustment

Intellisys Controller Operations

Push Button Controls

Settings and Calibration

Alerts and Faults Management

Scheduled Preventative Maintenance

Maintenance Schedule and Intervals

Table outlining recommended maintenance actions and intervals.

Maintenance Records Keeping

General Maintenance Procedures

General guidelines and requirements before performing maintenance.

Pressure Relief Valve Check

Procedure for monthly testing of the pressure relief valve.

Sheave Alignment Procedures

Drive Belt Maintenance

Shaft Seal Replacement

Guidelines for replacing the compressor's lip type shaft seals.

Inlet Air Filter Element Replacement

Coolant Filter Replacement

Coolant Change Procedure

Step-by-step guide for draining and refilling the compressor's coolant.

Coolant Separator Filter Element Replacement

Motor Lubrication Procedure

Troubleshooting Guide

Standard Control Troubleshooting

Identifies common troubles and corresponding check points for standard control systems.

Intellisys Control Troubleshooting

Diagnoses common issues and solutions for Intellisys controlled compressors.

Ingersoll-Rand EP 30 Specifications
