80447162
Revision B
June 2014
Save These Instructions
Contact-Cooled Rotary Screw Air Compressor
R30, R37, R45, R55, R75, R90, R110, R132, R160
Product Information
Information produit
FR
Información del producto
ES
Product Information
EN
Informações do produto
PT
93014.15.06
PRINT LANGUAGE
ENGLISH
SPANISH
FRENCH
PORTUGUESE

Table of Contents

Other manuals for Ingersoll-Rand R90

Preview: Product Maintenance Information
Product Maintenance Information32 pages
Preview: Product Information
Product Information48 pages

Questions and Answers

  • O
    Olivia DorseySep 23, 2025
    When to change HE filter in integrated dryer models of Ingersoll-Rand Air Compressor?
    • J
      John HendersonSep 23, 2025
      To address the issue of needing to change the HE filter in integrated dryer models of your Ingersoll-Rand Air Compressor: * If there is a faulty pressure transducer measurement, calibrate and validate the after cooler discharge and package discharge transducers. * If the moisture separator condensate drain trap is faulty, ensure the condensate drain system is functioning properly and condensate is being drained. * If there is a blockage in the dryer, ensure it's not due to freeze up from refrigerant leaks. * If the dryer HE filter is dirty or blocked, change the HE filter.
  • D
    dgonzalezAug 26, 2025
    What to do if Ingersoll-Rand R90 is stopped and will not restart?
    • T
      Taylor DodsonAug 27, 2025
      If your Ingersoll-Rand Air Compressor is stopped and won't restart, it could be due to the following reasons: * The controller has tripped the compressor and hasn't been reset. See Tables 4 and 5. * The emergency stop button has been pressed but not released. Identify the reason, repair the fault, disengage the button, and reset the controller. * The emergency stop button has been pressed and released, but the controller hasn't been reset. Repair the fault and reset the controller.
  • J
    Jessica RamirezAug 27, 2025
    Why does my Ingersoll-Rand R90 Air Compressor stop and not restart?
    • M
      Michelle SavageAug 27, 2025
      If your Ingersoll-Rand Air Compressor stops and will not restart, it could be due to: * A tripped drive controller. See Tables 4 and 5. * The controller has tripped the compressor. See Tables 4 and 5. * The maximum number of starts per hour has been exceeded.
  • T
    Troy ShawAug 28, 2025
    Why is the discharge air from my Ingersoll-Rand Air Compressor too hot?
    • B
      Barbara CherryAug 28, 2025
      If the discharge air from your Ingersoll-Rand Air Compressor is too hot, consider these potential causes: * High ambient temperature. Review the installation and system parameters. * Insufficient cooling air. Check the ducting and cooling air path, and verify the direction of blower rotation. * Dirty or blocked aftercooler (cooling air side). Clean or replace the aftercooler.
  • K
    Kayla HansenSep 23, 2025
    What to do if Ingersoll-Rand Air Compressor stops but there is no alarm message?
    • M
      Matthew RoySep 23, 2025
      If your Ingersoll-Rand Air Compressor stops but there is no alarm message: * There may be a loss of outputs of control power. Check the controller outputs (110V AC) power supply (fuses/mini circuit breaker).
  • C
    Cindy SmithNov 24, 2025
    What to do if Ingersoll-Rand Air Compressor will not meet pressure requirements?
    • K
      Katie HermanNov 24, 2025
      If your Ingersoll-Rand Air Compressor isn't meeting the required pressure, consider the following: * Check for air loss due to pipe, hose, joint, or seal failures. Repair or replace any faulty components. * Inspect for air loss due to a blowdown valve stuck open and repair or replace if needed. * Look for air loss through the pressure relief valve if it's not seating correctly or is set incorrectly; repair or replace it. * Check for air loss due to a moisture separator drain trap stuck open; repair or replace it if necessary. * Examine the inlet grill or ducting for blockages and clean them. * Replace the air filter if it's dirty or collapsed. * Recalibrate or replace the pressure transducer if it is faulty, incorrectly calibrated, or experiencing EMF interference. * Verif...
  • G
    gregory68Sep 12, 2025
    Why do I need to check setpoints on Ingersoll-Rand Air Compressor?
    • M
      Miguel ThomasSep 12, 2025
      You may need to check the setpoints on your Ingersoll-Rand Air Compressor if: * The controller software has been changed. Recalibrate all sensors and check the setpoints.
  • R
    Robert PinedaSep 12, 2025
    What to do if sensor failure occurs in Ingersoll-Rand Air Compressor?
    • K
      Kevin MullinsSep 12, 2025
      If a sensor failure occurs in your Ingersoll-Rand Air Compressor: * The sensor may be missing or faulty. Install, repair, or replace the faulty sensor.
  • K
    Kelly HintonSep 5, 2025
    What causes excessive coolant consumption in Ingersoll-Rand Air Compressor?
    • E
      Elizabeth NelsonSep 5, 2025
      Excessive coolant consumption in your Ingersoll-Rand Air Compressor can be due to: * A coolant system leak. Repair or replace the leaking components. * See also ‘discharge air is contaminated with coolant’.
  • C
    Cheryl JohnsonSep 3, 2025
    Why is pressure too high in Ingersoll-Rand Air Compressor because speed is not reducing?
    • D
      Donna HarrisSep 3, 2025
      If the pressure produced by your Ingersoll-Rand Air Compressor is too high because the speed isn't reducing as demand decreases: * The controller settings may be incorrect. Check and modify the settings. * The pressure transducer may be faulty, incorrectly calibrated, or not receiving a pressure signal. Recalibrate or replace it.

Summary

SAFETY

General Safety Precautions

Follow all Danger, Warning, Caution, and Operating Instructions for safe operation.

Electrical Safety

Covers grounding, wiring, VSD considerations, and high voltage protection.

INSTALLATION GUIDELINES

Electrical Requirements

Details on general electrical, grounding, and VSD-specific wiring.

VSD OPERATING INSTRUCTIONS

Basic Operation and Controls

Covers starting, stopping, warm-up, blower control, and emergency procedures.

Start Sequence Details

Steps involved in the compressor's start sequence, including checks and ramp-up.

Stop Sequence Details

Procedures for normal stopping, blowdown, and system pressure management.

XE-90 M CONTROLLER INTERFACE

User Interface Navigation

Explanation of the controller's keys, display layout, and navigation methods.

OPERATOR SETTINGS FOLDER

Operator Settings Parameters

Adjustable parameters for pressure, modes, and timers.

WARNING EVENTS LIST

TRIP EVENTS AND HISTORY

Understanding Trip Events

FACTORY SETTINGS MANAGEMENT

Password Management

Compressor Parameter Configuration

MODBUS COMMUNICATION AND CONTROL

Modbus Addressing and Setup

Modbus Master Configuration

X-SERIES SYSTEM INTEGRATION

Enabling System Control

Steps to enable COM control and Auto-Restart for X-Series system integration.

Ingersoll-Rand R90 Specifications

General IconGeneral
BrandIngersoll-Rand
ModelR90
CategoryAir Compressor
LanguageEnglish
