Configuration manual
Configuration 9
2.4 Access to the device modification menu
Once the Previdia Compact system has been configured it is necessary to set the parameters, or change the default
programming of the devices connected to the control panel, individually or in a group.
The Previdia Compact control panel provides a direct programming option on the control panel for its connected
devices and their logical groups (zones and output groups) without need of accessing the “Configuration” section
(paragraph 2.3). To access it, you must access the programming phase of the control panel (paragraph 2.2) and then
press the Modify button on the menu that appears on the screen.
The section you access will show Ia list containing the access buttons to the programming subsections::
• Zones (refer to paragraph 4.3)
• Output groups (refer to paragraph 4.4)
• I/O Lines (refer to paragraph 4.2)
• Loop points (refer to paragraph 4.1)
Icon Function buttons Display
Access to the configuration of the
general parameters of the control panel.
Refer to paragraph 3.1
Access to the configuration of the
general parameters of the Inim Cloud
service.
Refer to paragraph 3.2.
Access to the configuration of the
extinction channel.
Refer to paragraph 3.10
Access to the configuration of the
Ethernet network.
Refer to paragraph 3.3
Access to the configuration of the
Hornet+ network.
Refer to paragraph 3.4
Access to the configuration of the loops
(loop 1 and loop 2).
Refer to paragraph 3.5
Access to the functions provided by the
SD card.
Refer to paragraph 3.6
Access to the configuration of the inputs
and outputs provided by the control
panel terminals.
Refer to paragraph 4.2
Access to the configuration of the
control panel access codes.
Refer to paragraph 3.8
Access to the configuration of the
general parameters of the remote
communicator.
Refer to paragraph 3.9
Access to the configuration of the
power supply.
Refer to paragraph 5.1
