Falcon Plus User Manual
6
Indicator
Light Status
Description
Indicator Light Status
In shutdown and standby mode, the current power is 0-25%, 25-50%,
50-75%, 75-100% from the left.
Blue LED Light
Represent the mode state after Turning on, in proper sequence from left to
right are: PF mode, HL mode, FPV mode, Flashlight mode(FL), under Lock
mode(GL) the LED all bright, Vertical Shooting Mode (FL flashes).
Green LED Light
Display the Bluetooth connection status. It is always on when the Bluetooth
is connected while it is always off when no connection. After pairing is
cleared, the light will flash slowly during the Bluetooth scanning, if there is
connected then always on if not then off light.
Red LED Light
Display the current upgrade status. The red-light flashes rapidly during
upgrade, and it will turn off after three seconds when upgrade completed.
When the power is lower then 10% the red-light flashes slowly, Red light
flashing indicates upgrade failure
2021 INKEE Falcon All Rights Reserved
Mode Switch Button
1、Illustration
① Single click to switch PF-HL-FPV mode.
② Double click to enter vertical shooting mode, double click again to ener Flashlight Mode.
Single click to exit to HL mode.
③ Long press the Trigger Button to enter GL Mode(Lock Mode), release to back to previous
mode(GL Mode works only under PF or HL Mode).
2、The current mode of the stabilizer can be identified by the status of the indicator light.
PF Pan Following HL Pan/Tilt Following FPV Three axis all Following
PF HL FPV
FL
PF HL FPV
FL
PF HL FPV
FL
