Specifications
UI/UX
Display/interaction
LED ring for charging status;
2 LED indicators for authentication and vehicle connection status,
1 LED button for Bluetooth connection
Notes for use Attached to the side of the eBox as a graphic
External accessories
Personal protection
to be installed
in sub-distribution
Fault current protection switch type A (RCD type A):
32A connection: ABB F204A-40/0.03, type A, 4-pole (short-time delay, operating voltage: 230/400 V AC)
16A connection: ABB F204A-25/0.03, type A, 4-pole (short-time delay, operating voltage: 230/400 V AC)
Short-circuit/overload protection
to be installed
in sub-distribution
Circuit breaker:
32A connection: ABB S203-NA K40A (rated switching capacity: 6,000 A)
16A connection: ABB S203-NA K20A (rated switching capacity: 6,000 A)
