Inogen One G3 Technical Manual

CONFIDENTIAL and
PROPRIETARY
96-03996-00-01 revF
DCR-15-284
INOGEN ONE G3 OXYGEN CONCENTRATOR
TECHNICAL MANUAL
Page 17 of 20
Cm
In
Cm
In
Cm
In
No battery
22.2
8.75
7.6
3.0
18.4
7.25
8 cell
battery
22.2
8.75
7.6
3.0
21.0
8.25
16 cell
battery
22.2
8.75
7.6
3.0
23.5
9.25
Weight:
4.8 pounds (includes 8 cell battery)
Noise:
<42 dB (G3) or 39 db (G3HF) on flow setting 2
Warm-Up Time:
Approximately 2 minutes
Oxygen
Concentration:
90 + 6/-3%
Flow Control Settings:
1,2,3,4,and 5 (G3HF only)
Power:
AC Power Supply
Input:100 to 240 VAC, 50 to 60 Hz, 1.0A to 0.5A
Output 19 VDC, 85 W
DC Input: 13.5 to 19 VDC, 10A
Rechargeable Battery: Voltage12.0 to 16.8 VDC,
Battery Duration:
Approximately 2 to 4 hours for 8 cell battery
Approximately 4 to 8 hours for 16 cell battery
Battery Charging
Time:
Approximately 2.25 to 4.25 hours for 8 cell battery
Approximately 4.25 to 8.00 hours for 16 cell battery
Environmental Ranges
Intended for Use:
Temperature: 40 - 104
o
F (4 - 40
o
C)
Humidity: 0% to 95%, non-condensing
Classifications
Mode of Operation:
Continuous Duty
Type of Protection Against Electrical Shock:
Class II
Degree of Protection Against Electrical
Shock:
Type BF
Not intended for cardiac application
Degree of Protection Against Ingress of
Water:
Concentrator: IP 20
w/carry bag: IP 22
