Inovance Easy521 User Manual

‑16‑
No. Terminal
type
Terminal code Assignment Indicator
color
Description
③ DIP switch
RUN/STOP Used to control
the operation of
the master.
‑ ‑
④
Type‑C
interface
Used for
communication
with PC.
‑ ‑
⑤/‑
⑥
Extension
card slot
01/02 Used for
function
extension.
‑ For details of
extension card
options, see "
Appendix: Extension
Card Options
" on
page 41
.
⑦ RS485
485+ RS485
communication
signal+
‑ ‑
485‑ RS485
communication
signal‑
‑ ‑
GND RS485
communication
GND
‑ ‑
⑧
Power
supply
interface
+24V 24 VDC power
supply (+)
‑ ‑
0V 24 VDC power
supply (‑)
‑ ‑
PE ‑ ‑
⑨
EtherCAT
interface
EtherCAT Used for
EtherCAT
communica‑
tion.
‑ ‑
⑩
I/O terminal
– 8 inputs and 8
outputs
‑ See details in "
3.1
Layout of Terminals
"
on page 30 .
⑪/‑
⑫
Ethernet
port
EtherNET1/
EtherNET2
Ethernet RJ45
interface
‑ ‑
