‑20‑
Item Specifications
Short circuit protection Providing protection against short circuit of each circuit
(The short circuit protection state can be cancelled through
a power cycle.)
External inductive load
protection
Connect a flywheel diode
[1]
when connecting the external
inductive load.
Output action display The output indicator lights up (controlled by software)
when the output is in drive state.
[1]: D: 1N4001 or similar diodes are shown in the following figure.
