3.7 Arrangement 2: Power Wiring Diagram
Main Motor driven by MDI and Fan by Power-line
R S T
U V W
L1 L2 L3
QF1
U1 V1 W1
M
MD320
3-phase AC power supply
MDI
Main
motor
CT2
M
Fan
QF2
H0U-88B1G
56
KM1
ACC
Figure 3-5 Main Motor Driven by MDI and Fan by Power-line
