Inovance IS620PS1R6I Manual

2 Wiring
2
- 26 -
■
Connector Kit
Motor Model Connector Kit
ISMH1-*******-U1***
ISMH1-*******-U2***
ISMH4-*******-U1***
ISMH4-*******-U2***
S6-C1
Including: CN1 terminal, CN2 terminal, 6-pin connector, 9-pin connector
ISMH1-*******-A3***
ISMH4-*******-A3***
ISMH2-*******-U1***
ISMH2-*******-U2***
S6-C2
Including: CN1 terminal, CN2 terminal, 20-18 military spec. plug (elbow),
20-29military spec. plug (elbow)
ISMH2-*******-A3***
ISMH3-*******-U1***
ISMH3-*******-U2***
ISMH3-*******-A3***
(1.8 kW and below)
S6-C2
Including: CN1 terminal, CN2 terminal, 20-18military spec. plug (elbow),
20-29military spec. plug (elbow)
ISMH3-*******-U1***
ISMH3-*******-U2***
ISMH3-*******-A3***
(2.9 kW)
S6-C3
Including: CN1 terminal, CN2 terminal, 20-22military spec. plug (elbow),
20-29military spec. plug (elbow)
ISMH3-*******-U1***
ISMH3-*******-U2***
ISMH3-*******-A3***
(2.9 kW and above)
Note
If you prepare cables yourself rather than use Inonvace matching cables , the connector kit is
required.
■
Battery Kit of Absolute Encoder Motor
If Inovance absolute encoder motor is used, the optional battery kit S6-C4 (battery, battery box) is required
besides the matching cables.
Communication Cable
Cable Model Description
S6-L-T00-3.0 Servo drive to PC communication cable
S6-L-T01-0.3 Communication cable for multi-drive parallel connection
S6-L-T02-2.0 Servo drive to PLC communication cable
S6-L-T03-0.0 Plug for termination resistor for servo drive communication
