Inovance ISMG2-57D20CD-A3 F Series User Manual

6 Parameter Table
6
- 84 -
Function
Code
Parameter Name Setting Range Unit Default
ET Pro
CM
H11-25
Acceleration/Deceleration time of
3rd displacement
0 to 65535 ms (s) 10
Im Ru
P
H11-26 Waiting time after 3rddisplacement 0 to 10000 ms (s) 10
Im Ru
P
H11-27 4th displacement
-1073741824 to
1073741824
Ref 10000
Im Ru
P
H11-29
Maximum running speed of 4th
displacement
1 to 6000 RPM 200
Im Ru
P
H11-30
Acceleration/Deceleration time of
4th displacement
0 to 65535 ms (s) 10
Im Ru
P
H11-31 Waiting time after 4th displacement 0 to 10000 ms (s) 10
Im Ru
P
H11-32 5th displacement
-1073741824 to
1073741824
Ref 10000
Im Ru
P
H11-34
Maximum running speed of 5th
displacement
1 to 6000 RPM 200
Im Ru
P
H11-35
Acceleration/Deceleration time of
5th displacement
0 to 65535 ms (s) 10
Im Ru
P
H11-36 Waiting time after 5th displacement 0 to 10000 ms (s) 10
Im Ru
P
H11-37 6th displacement
-1073741824 to
1073741824
Ref 10000
Im Ru
P
H11-39
Maximum running speed of 6th
displacement
1 to 6000 RPM 200
Im Ru
P
H11-40
Acceleration/Deceleration time of
6th displacement
0 to 65535 ms (s) 10
Im Ru
P
H11-41 Waiting time after 6th displacement 0 to 10000 ms (s) 10
Im Ru
P
H11-42 7th displacement
-1073741824 to
1073741824
Ref 10000
Im Ru
P
H11-44
Maximum running speed of 7th
displacement
1 to 6000 RPM 200
Im Ru
P
H11-45
Acceleration/Deceleration time of
7th displacement
0 to 65535 ms (s) 10
Im Ru
P
H11-46 Waiting time after 7th displacement 0 to 10000 ms (s) 10
Im Ru
P
H11-47 8th displacement
-1073741824 to
1073741824
Ref 10000
Im Ru
P
H11-49
Maximum running speed of 8th
displacement
1 to 6000 RPM 200
Im Ru
P
H11-50
Acceleration/Deceleration time of
8th displacement
0 to 65535 ms (s) 10
Im Ru
P
H11-51 Waiting time after 8th displacement 0 to 10000 ms (s) 10
Im Ru
P
H11-52 9th displacement
-1073741824 to
1073741824
Ref 10000
Im Ru
P
H11-54
Maximum running speed of 9th
displacement
1 to 6000 RPM 200
Im Ru
P
H11-55
Acceleration/Deceleration time of
9th displacement
0 to 65535 ms (s) 10
Im Ru
P
H11-56 Waiting time after 9th displacement 0 to 10000 ms (s) 10
Im Ru
P
