MD380 User Manual Selection and Dimensions
- 277 -
AC Drive Model
MCCB
(A)
Contactor
(A)
Cable of Input
Side Main Circuit
(mm
2
)
Cable of Output
Side Main Circuit
(mm
2
)
Cable of
Control Circuit
(mm
2
)
MD380T37G 80 80 25 25 1.0
MD380T45G 100 115 35 35 1.0
MD380T55G 125 125 50 50 1.0
MD380T75G 160 185 70 70 1.0
MD380T90G 200 225 95 95 1.0
MD380T110G 225 225 120 120 1.0
MD380T132G 315 330 120 120 1.0
MD380T160G 350 400 150 150 1.0
MD380T200G 400 400 185 185 1.0
MD380T220G 500 500 240 240 1.0
MD380T250G 500 500 120 x 2 120 x 2 1.0
MD380T280G 630 630 120 x 2 120 x 2 1.0
MD380T315G 630 630 150 x 2 150 x 2 1.0
MD380T355G 700 800 185 x 2 185 x 2 1.0
MD380T400G 800 800 240 x 2 240 x 2 1.0
Three-phase 480 V
MD380-5T0.7GB 4 9 0.75 0.75 0.5
MD380-5T1.5GB 6 9 0.75 0.75 0.5
MD380-5T2.2GB 10 12 0.75 0.75 0.5
MD380-5T3.7GB 16 18 1.5 1.5 0.5
MD380-5T5.5GB 20 25 2.5 2.5 0.75
MD380-5T7.5GB 25 25 4.0 4.0 0.75
MD380-5T11GB 32 32 4.0 4.0 0.75
MD380-5T15GB 40 40 6.0 6.0 0.75
MD380-5T18.5G 50 50 10 10 1.0
MD380-5T22G 50 50 10 10 1.0
MD380-5T30G 63 63 16 16 1.0
MD380-5T37G 80 80 25 25 1.0
MD380-5T45G 100 115 35 35 1.0
MD380-5T55G 125 125 50 50 1.0
MD380-5T75G 160 185 70 70 1.0
MD380-5T90G 200 225 95 95 1.0
MD380-5T110G 225 225 120 120 1.0
MD380-5T132G 315 330 120 120 1.0
MD380-5T160G 350 400 150 150 1.0
MD380-5T200G 400 400 185 185 1.0
MD380-5T220G 500 500 240 240 1.0
