Inovance MD380T5.5GB

Selection and Dimensions
MD380 User Manual
- 278 -
AC Drive Model
MCCB
(A)
Contactor
(A)
Cable of Input
Side Main Circuit
(mm
2
)
Cable of Output
Side Main Circuit
(mm
2
)
Cable of
Control Circuit
(mm
2
)
MD380-5T250G 500 500 120 x 2 120 x 2 1.0
MD380-5T280G 630 630 120 x 2 120 x 2 1.0
MD380-5T315G 630 630 150 x 2 150 x 2 1.0
MD380-5T355G 700 800 185 x 2 185 x 2 1.0
MD380-5T400G 800 800 240 x 2 240 x 2 1.0
Three-phase 690 V
MD380-7T55G 80 80 16 16 1.0
MD380-7T75G 100 115 25 25 1.0
MD380-7T90G 125 125 35 35 1.0
MD380-7T110G 160 185 50 50 1.0
MD380-7T132G 180 200 70 70 1.0
MD380-7T160G 225 225 95 95 1.0
MD380-7T200G 250 250 120 120 1.0
MD380-7T220G 315 315 120 120 1.0
MD380-7T250G 315 315 150 150 1.0
MD380-7T280G 350 400 150 150 1.0
MD380-7T315G 400 400 185 185 1.0
MD380-7T355G 400 400 185 185 1.0
MD380-7T400G 500 500 240 240 1.0
MD380-7T450G 630 630 120 x 2 120 x 2 1.0
MD380-7T500G 630 630 150 x 2 150 x 2 1.0
8.5 Selection and Installation of External DC Reactor
8.5.1 Installation Mode of External DC Reactor
The MD380 series AC drives of over 75 kW power (2T is 37 kW) are congured with an
external DC reactor as standard. The DC reactor is packed in separate wooden box for
delivery.
When installing the DC reactor, remove the shorting copper busbar between the main circuit
connection terminals P and +. Then connect the DC reactor between terminals P and +
(no polarity requirement). The copper busbar is not used any longer after the installation is
complete.
Note
Customized models can be provided for special requirements.
.
