1 Product Information
1
Item Specication
Protection
functions
(Continued)
Leveling switch fault
protection
Protection at fault of leveling switch
EEPROM fault Self-check at power-on
Display
Keypad 3-digit LED display, providing certain commissioning functions
Operating panel
5-digit LED display, viewing and modifying most parameters and
monitoring system state
Mobile phone commissioning Viewing and changing system state
Environment
Ambient temperature
-10°C to 40°C (de-rated if the ambient temperature is above
40°C, maximum temperature: 50°C)
Humidity Maximum relative humidity 95%, non-condensing
Vibration < 5.9 m/s2 (0.6g)
Storage temperature -–20°C to 60°C (temperature during transportation)
Location Indoor (no corrosive gas or dust)
Pollution degree PD2
Power supply system TN/TT
Altitude Below 1000 m (de-rated 1% for each 100 m higher)
Structure
Ingress protection IP20
Cooling method Forced air cooling
Mounting method Cabinet installation
1.5 Selection of Braking Resistor
Table 1-3 Braking component selection
Controller Model
Power of
Applicable Motor
(kW)
Max.
Resistance
(Ω)
Min.
Resistance
(Ω)
Power of
Braking Resistor
(W)
Braking Unit
Single-phase 220 V, range:220 to 240 V
NICE-L-C-2002 1.1 145.0 125.0 300
Built-in
NICE-L-C-2003 1.5 105.0 90.0 450
220-NICE-L-C-4007 2.2 72.0 63.0 600
220-NICE-L-C-4011 3.7 43.0 37.0 1100
220-NICE-L-C-4015 4.0 40.0 35.0 1200
220-NICE-L-C-4018
5.5 29.0 25.0 1600
220-NICE-L-C-4018F
220-NICE-L-C-4022
11.0 18.0 16.0 3500
Built-in
220-NICE-L-C-4022F
220-NICE-L-C-4030
15.0 13.0 13.0 4500
220-NICE-L-C-4030F
Three-phase 220 V, range: 220 to 240 V
NICE-L-C-2002 2.2 72.0 65.0 600
Built-in
NICE-L-C-2003 3.7 54.0 50.0 1100
220-NICE-L-C-4007 4.0 40.0 35.0 1200
