1 Product Information
- 18 -
Table 1-3 Cables for lead wire-type (Z-S series) motors
Cable Type
Cable Length (m)
3.0 5.0 10.0
Power cable (without brake) S6-L-M00-3.0 S6-L-M000-5.0 S6-L-M000-10.0
Power cable (with brake) S6-L-B00-3.0 S6-L-B000-5.0 S6-L-B000-10.0
Absolute encoder cable S6-L-P020-3.0 S6-L-P020-5.0 S6-L-P020-10.0
Incremental encoder cable S6-L-P010-3.0 S6-L-P010-5.0 S6-L-P010-10.0
Table 1-4 Cables for terminal-type (Z series) motors with front cable outlets (drag chain)
Cable Type
Cable Length (m)
3.0 5.0 10.0
Power cable (without brake) S6-L-M007-3.0-T S6-L-M007-5.0-T S6-L-M007-10.0-T
Power cable (with brake) S6-L-B007-3.0-T S6-L-B007-5.0-T S6-L-B007-10.0-T
Absolute encoder cable S6-L-P024-3.0-T S6-L-P024-5.0-T S6-L-P024-10.0-T
Incremental encoder cable S6-L-P014-3.0-T S6-L-P014-5.0-T S6-L-P014-10.0-T
Table 1-5 Cables for terminal-type (Z series) motors with rear cable outlets (drag chain)
Cable Type
Cable Length (m)
3.0 5.0 10.0
Power cable (without brake) S6-L-M008-3.0-T S6-L-M008-5.0-T S6-L-M008-10.0-T
Power cable (with brake) S6-L-B008-3.0-T S6-L-B008-5.0-T S6-L-B008-10.0-T
Absolute encoder cable S6-L-P025-3.0-T S6-L-P025-5.0-T S6-L-P025-10.0-T
Incremental encoder cable S6-L-P015-3.0-T S6-L-P015-5.0-T S6-L-P015-10.0-T
Table 1-6 Cables for lead wire-type (Z-S series) motors (drag chain)
Cable Type
Cable Length (m)
3.0 5.0 10.0
Power cable (without brake) S6-L-M00-3.0-T S6-L-M000-5.0-T S6-L-M000-10.0-T
Power cable (with brake) S6-L-B00-3.0-T S6-L-B000-5.0-T S6-L-B000-10.0-T
Absolute encoder cable S6-L-P020-3.0-T S6-L-P020-5.0-T S6-L-P020-10.0-T
Incremental encoder cable S6-L-P010-3.0-T S6-L-P010-5.0-T S6-L-P010-10.0-T
