Inovance MS1 Series User Manual

1 Product Information
- 9 -
MS1H3-44C15CD 180
1500 3000
1.90
88.9
(90.8)
[4]
380MS1H3-55C15CD 180 1.74
107
(109.5)
[4]
MS1H3-75C15CD 180 1.99
141
(143.1)
[4]
MS1H4-40B30CB 60
3000 6000
0.53
0.657
(0.667)
[4]
220
MS1H4-75B30CB 80 0.58
2
(2.012)
[4]
NOTE
◆
[1] The motor with oil sealing must be derated by 10% during use.
◆
[2]Values in () represent the maxiumum torque of the motor at a speed of 2000
rpm.
◆
[3]Values in () represent the maxiumum torque of the motor at a speed of 2000
rpm.
◆
[4] Parameters in () are for the motor with brake.
The parameters in the preceding table are the values when the motor works together
with Inovance servo drive and the armature coil temperature is 20ºC.
The preceding features are based on the cooling conditions when the following
heatsinks are installed.
MS1H1/MS1H4: 250 x 250 x 6 mm (aluminum)
MS1H2-10C to 25C：300 x 300 x 12mm（aluminum）
MS1H2-30C to 50C：400 x 400 x 20mm（aluminum）
MS1H3-85B to 18C：400 x 400 x 20mm（iron）
MS1H3-29C to 75C：360 x 360 x 5mm（dual-layer aluminum plate）
1.3.3 Overload Characteristics
Load Ratio (%) Running Time (s)
120 230
130 80
140 40
150 30
160 20
170 17
180 15
190 12
200 10
210 8.5
220 7
230 6
240 5.5
250 5
300 3
350 2
