Inovance MS1 Series User Manual

1 Product Information
- 8 -
MS1H3-44C15CD 180 4.4 28.4 71.1 16.50 40.50
MS1H3-55C15CD 180 5.5 35.0 87.6 20.85 52.00
MS1H3-75C15CD 180 7.5 48.0 119 25.70 65.00
MS1H4-40B30CB 60 0.4 1.27 4.46 2.8 10.1
MS1H4-75B30CB 80 0.75 2.39 8.36 4.8 16.9
Model
Frame Size
(mm)
Rated
Speed
(rpm)
Maximum
Speed
(rpm)
Torque
Coe󶎀cient
(N·m/Arms)
Rotor
Inertia
(kg·cm
2
)
Voltage
(Vdc)
MS1H1-05B30CB 40
3000 6000
0.15
0.026
(0.028)
[4]
220
MS1H1-10B30CB 40 0.26
0.041
(0.043)
[4]
MS1H1-20B30CB 60 0.46
0.207
(0.220)
[4]
MS1H1-40B30CB 60 0.53
0.376
(0.390)
[4]
MS1H1-55B30CB 80 0.49 1.06
MS1H1-75B30CB 80 0.58
1.38
(1.43)
[4]
MS1H1-10C30CB 80 0.46 1.75
MS1H2-10C30CB 100
3000
6000 0.47
1.87
(3.12)
[4]
220
MS1H2-15C30CB 100 5000 0.54
2.46
(3.71)
[4]
MS1H2-10C30CD 100 6000 0.89
1.87
(3.12)
[4]
380
MS1H2-15C30CD 100
5000
1.07
2.46
(3.71)
[4]
MS1H2-20C30CD 100 1.14
3.06
(4.31)
[4]
MS1H2-25C30CD 100 1.11
3.65
(4.90)
[4]
MS1H2-30C30CD 130 1.16
7.72
(10.22)
[4]
MS1H2-40C30CD 130
3000 5000
1.16
12.1
(14.6)
[4]
380
MS1H2-50C30CD 130 1.16
15.4
(17.9)
[4]
MS1H3-85B15CB 130
1500 3000
0.95
13.3
(14)
[4]
220
MS1H3-13C15CB 130 0.95
17.8
(18.5)
[4]
MS1H3-85B15CD 130 1.87
13.3
(14)
[4]
380
MS1H3-13C15CD 130 1.87
17.8
(18.5)
[4]
MS1H3-18C15CD 130 1.87
25
(25.7)
[4]
MS1H3-29C15CD 180 1.82
55
(57.2)
[4]
