DIAGNOSTIC CODES FOR CBD6S
CODES NAME DESCRIPTION POTENTIAL CAUSE SOLUTION/TROUBLESHOOTING
E15 Power limit
System has reached
its power limitation
• Mains cable pulled during driving
• Internal fault
• Many times will see
this alongside E10
• "E15 is when power regulator
has adjusted speed down on
actuators without any signicant
current draw, usually caused
by power supply dropping."
• Check mains cable is not caught,
and is allowed to freely travel
• Use strain-relief loop
built into control box
E16 Key Error
Illegal keys pressed
(handled internally
in DP1C).
• Hitting multiple buttons
simultaneously
• Check switch
E17 Safety missing
LIN bus unit does not
support safety feature
• * DP1C/DPF1C does not
have up-to-date software
• >Try DP with more recent software
version (version printed on label)
E18
Missing
Initialization plug
A special service tool
is required to change
number of channels
to the system
• [BASELIFT Only]
• Service tool missing
from BASELIFT system
when initializing
• Add service tool
E23 Ch1 missing
Channel 1 is
detected missing
• Disconnection
• Faulty motor cable
• Faulty motor in leg
• Check Motor cable
connections and Integrity
• Change Motor cable or Desk Leg
• Initialize the system
E24 Ch2 missing
Channel 2 is
detected missing
• Disconnection
• Faulty motor cable
• Faulty motor in leg
• Check Motor cable
connections and Integrity
• Change Motor cable or Desk Leg
• Initialize the system
E25 Ch3 missing
Channel 3 is
detected missing
• Disconnection
• Faulty motor cable
• Faulty motor in leg
• Check Motor cable
connections and Integrity
• Change Motor cable or Desk Leg
• Initialize the system
E26 Ch4 missing
Channel 4 is
detected missing
• Disconnection
• Faulty motor cable
• Faulty motor in leg
• Check Motor cable
connections and Integrity
• Change Motor cable or Desk Leg
• Initialize the system
E29 Ch1 type
Channel 1 is not same
type as when initialized
• Change in Desk Leg type
• Loose wire inside motor
• Check Desk Leg type
• Change Desk Leg
• Initialize the system
