DIAGNOSTIC CODES FOR CBD6S
CODES NAME DESCRIPTION POTENTIAL CAUSE SOLUTION/TROUBLESHOOTING
E30 Ch2 type
Channel 2 is not
same type as when
initialized or not same
type as channel 1
• Change in Desk Leg type
• Loose wire inside motor
• Check Desk Leg type
• Change Desk Leg
• Initialize the system
E31 Ch3 type
Channel 3 is not
same type as when
initialized or not same
type as channel 1
• Change in Desk Leg type
• Loose wire inside motor
• Check Desk Leg type
• Change Desk Leg
• Initialize the system
E32 Ch4 type
Channel 4 is not
same type as when
initialized or not same
type as channel 1
• Change in Desk Leg type
• Loose wire inside motor
• Check Desk Leg type
• Change Desk Leg
• Initialize the system
E35 Ch1 pulse fail
Channel 1 had to
many pulse errors
• Loose/faulty cable
• Hall sensor PCB
• Check motor cable
connections and integrity
• Initialize the system
• Change Desk Leg
E36 Ch2 pulse fail
Channel 2 had to
many pulse errors
• Loose/faulty cable
• Hall sensor PCB
• Check motor cable
connections and integrity
• Initialize the system
• Change Desk Leg
E37 Ch3 pulse fail
Channel 3 had to
many pulse errors
• Loose/faulty cable
• Hall sensor PCB
• Check motor cable
connections and integrity
• Initialize the system
• Change Desk Leg
E38 Ch4 pulse fail
Channel 4 had too
many pulse errors
• Loose/faulty cable
• Hall sensor PCB
• Check motor cable
connections and integrity
• Initialize the system
• Change Desk Leg
E41 Ch1 overload up
Overload up occurred
on channel 1
• Leg is overloaded
• Hit obstruction
• Reached end stop (before
initialization at upper
end-stop occurs)
• Remove obstruction
• Remove load
• Initialize if necessary
E42 Ch2 overload up
Overload up occurred
on channel 2
• Leg is overloaded
• Hit obstruction
• Reached end stop (before
initialization at upper
end-stop occurs)
• Remove obstruction
• Remove load
• Initialize if necessary
Error Codes
Height Adjustable Table – User Guide | October 2019 15
