DIAGNOSTIC CODES FOR CBD6S
CODES NAME DESCRIPTION POTENTIAL CAUSE SOLUTION/TROUBLESHOOTING
E43 Ch3 overload up
Overload up occurred
on channel 3
• Leg is overloaded
• Hit obstruction
• Reached end stop (before
initialization at upper
end-stop occurs)
• Remove obstruction
• Remove load
• Initialize if necessary
E44 Ch4 overload up
Overload up occurred
on channel 4
• Leg is overloaded
• Hit obstruction
• Reached end stop (before
initialization at upper
end-stop occurs)
• Remove obstruction
• Remove load
• Initialize if necessary
E47
Ch1 overload
down
Overload down
occurred on channel 1
• Hit obstruction
• Remove obstruction
• Initialize if necessary
E48
Ch2 overload
down
Overload down
occurred on channel 2
• Hit obstruction
• Remove obstruction
• Initialize if necessary
E49
Ch3 overload
down
Overload down
occurred on channel 3
• Hit obstruction
• Remove obstruction
• Initialize if necessary
E50
Ch4 overload
down
Overload down
occurred on channel 4
• Hit obstruction
• Remove obstruction
• Initialize if necessary
E53 Ch1 anti-col
Anti-collision triggered
on channel 1
• Hit obstruction
• Remove obstruction
• Initialize if necessary
E54 Ch2 anti-col
Anti-collision triggered
on channel 2
• Hit obstruction
• Remove obstruction
• Initialize if necessary
E55 Ch3 anti-col
Anti-collision triggered
on channel 3
• Hit obstruction
• Remove obstruction
• Initialize if necessary
E56 Ch4 anti-col
Anti-collision triggered
on channel 4
• Hit obstruction
• Remove obstruction
• Initialize if necessary
E59 Ch1 SLS/PIEZO
Safety limit switch
activated on channel 1
• Hit obstruction
• Remove obstruction
• Initialize if necessary
E60 Ch2 SLS/PIEZO
Safety limit switch
activated on channel 2
• Hit obstruction
• Remove obstruction
• Initialize if necessary
Error Codes
