DIAGNOSTIC CODES FOR CBD6S
CODES NAME DESCRIPTION POTENTIAL CAUSE SOLUTION/TROUBLESHOOTING
E61 Ch3 SLS/PIEZO
Safety limit switch
activated on channel 3
• Hit obstruction
• Remove obstruction
• Initialize if necessary
E62 Ch4 SLS/PIEZO
Safety limit switch
activated on channel 4
• Hit obstruction
• Remove obstruction
• Initialize if necessary
E65 Ch1 pulse dir
Pulses counted wrong
direction in channel 1
• Motor poles are crossed
• Hall sensor Cables are crossed
• Check motor cable
connections and integrity
• Initialize the system
• Exchange Desk Leg
E66 Ch2 pulse dir
Pulses counted wrong
direction in channel 2
• Motor poles are crossed
• Hall sensor Cables are crossed
• Check motor cable
connections and integrity
• Initialize the system
• Exchange Desk Leg
E67 Ch3 pulse dir
Pulses counted wrong
direction in channel 3
• Motor poles are crossed
• Hall sensor Cables are crossed
• Check motor cable
connections and integrity
• Initialize the system
• Exchange Desk Leg
E68 Ch4 pulse dir
Pulses counted wrong
direction in channel 4
• Motor poles are crossed
• Hall sensor Cables are crossed
• Check motor cable
connections and integrity
• Initialize the system
• Exchange Desk Leg
E71 Ch1A short
Short circuit on channel 1
[If T-splitter is used,
short circuit on 1A]
• Damage to motor cable
• Damage to cable exiting
leg (if applicable)
• Inspect motor cable for
damage, replace if damaged
• Inspect cable exiting leg (if
applicable), replace if damaged.
E72 Ch1B short
Short circuit on channel 1
[If T-splitter is used,
short circuit on 1B]
• Damage to motor cable
• Damage to cable exiting
leg (if applicable)
• Inspect motor cable for
damage, replace if damaged
• Inspect cable exiting leg (if
applicable), replace if damaged.
E73 Ch2A short
Short circuit on channel 2
[If T-splitter is used,
short circuit on 2A]
• Damage to motor cable
• Damage to cable exiting
leg (if applicable)
• Inspect motor cable for
damage, replace if damaged
• Inspect cable exiting leg (if
applicable), replace if damaged.
Error Codes
