5. Factory/Service OSD Menu and Adjustment
5.1 To enter the Factory OSD Menu
First in the “Factory Option” item “Mode” choose “M” or “U”, default is “U”.
M-Can enter factory mode with factory RC or user RC.
U-Can enter factory mode only with user’s RC.
Note: Mode “M” is only used for factory production.
a. With factory RC (remote control)
1. Press “M” button and enter factory mode.
2. Press “Menu” button and enter factory OSD menu.
3. Press “CH+”/“CH-” button select the function menu, press “VOL+”/“VOL-” enter the selected
function menu. Press “VOL+”/“VOL-” button adjust values in the menu.
4. Press “M” button exit factory mode in the factory OSD menu.
When TV outgoing factory, user can not enter factory OSD menu with Factory Remote
b. With user’s RC
1. Power TV On
2. Press Menu button and call up User OSD Menu
3. If enter 1->9->9 ->9 in sequence. Note: If necessary, re-do number keys.DŽFactory OSD
appears.
4. If enter 1->9->7 ->7 in sequence.ˈBBY Service Factory OSD appears.
5. Press the standby button then AC turn off and restart the TV, which can exit factory OSD menu.
5.2 Factory OSD Menu
5.2.1 White Balance
Note: Different source has different WB values. Before adjusting, please change to desired source.
1. Auto Color
For VGA and Component Video sources, WB values must be adjusted.
Before adjusting, prepare the signal instruments such as DVD or K-8256 first, and find the video picture
with full color bars. Then please change to desired source.
source Timing Pattern Notes
1 ADC VGA 1024*768 Full color bars For VGA source
2 ADC HDTV 720P Full color bars For Component Video
