3.1.2 Model LC-32MFXX
a) Test voltage of X508 each pin on power board in turn shown as Table 3:
Table 3 Voltage of X508 each pin
X508 Pin 1
2、3 4、5
6 7 8 9 10
Min. (V) 0 11.3 0 2.85 4.85 4.85 3.25 4.85
Typical(V) 0 12.0 0 3.00 5.00 5.00 3.30 5.00
Max. (V) 0 12.6 0 3.15 5.35 5.35 3.30 5.35
b) Test voltage of X503 each pin on power board in turn shown as Table 4:
Table 4 Voltage of X503 each pin
X503
Pin 1～5 6～10
11 12
Min. (V) 23.8 0 3.25 4.85
Typical(V) 24.0 0 3.30 5.0
Max. (V) 25.2 0 3.30 5.35
3.1.3 Model LE-15/19/22/24MFXX
a) Test voltage of X502 each pin on power board in turn shown as Table 5:
Table 5 Voltage of X502 each pin
X502
Pin 1，2 3，4
5 6
Min. (V) 11.3 0 3.25 4.85
Typical(V) 12.0 0 3.30 5.00
Max. (V) 12.6 0 3.30 5.35
