NS-8PDVDA 8” portable DVD player
www.insignia-products.com
• Safety check—Upon completion of any service or repair to
this player, ask the service technician to perform safety checks
to determine that the player is in correct operating condition.
Getting to know your DVD player
Identification of controls and connections
The DVD player
Note
When player is in use for a long period of time, the surface of the
player will be hot. This will not affect its operation.
Item Name Function or control
1 DC Input jack Connects to the AC adapter.
2 Charge indicator LED Lights red when the battery is charging.
1
4
3
6
5
7
10
9
11
12
8
2
13
14
15
16
17
18
19
Top view - with
screen open
Front view
Side view
