Insignia NS-AC10P6WH-C User Manual

14
10,000 Btu Portable Air Conditioner
www.insigniaproducts.com
Installing your air conditioner
1 Screw the exhaust duct assembly to the air outlet on the back of your
portable air conditioner.
2 Measure the window size.
3 Adjust the length of the window sealing plate to fit the window
opening and secure it with a screw.
4 Install the window sealing plate in the window opening and secure it
with the screws provided.
The power cord length
shown is not to scale.
NS-AC10P6WH NS-AC10P6WH-C_15-0316_MAN_V2_ENG.fm Page 14 Thursday, March 19, 2015 8:04 AM

Insignia NS-AC10P6WH-C Specifications

General

Brand	Insignia
Model	NS-AC10P6WH-C
Category	Air Conditioner
Language	English
