Insignia 2.6 Cubic Foot Compact Refrigerator
www.insigniaproducts.com
8 Install the bottom hinge and the door stopper on the right bottom of
your refrigerator using the screws your previously removed. Tighten
the screws.
9 Align the hole in the bottom left of the refrigerator door with the
bottom hinge pin, then install the door on the hinge pin.
10 Place the top hinge pin into the top of the refrigerator door, then
install the top hinge on the top left of the refrigerator with the screws
your previously removed.
11 Check the fit and alignment (vertical and horizontal) of the door and
make sure it that moves freely open and closed, then tighten the
screws holding the top hinge.
12 Install the screw covers previously removed into the holes in the top
right of the refrigerator.
13 Adjust the leveling feet to level the refrigerator.
