16
www.insigniaproducts.com
INSTALLATION INSTRUCTIONS
Installing your dryer and washer vertically
Your dryer can be stacked on top of the NS-FWM27W1 washing
machine, using the included stacking kit. See “Stacking your washer
and dryer (optional)” on page 25 for stacking instructions.
Leave at least two inches between your appliances’ sides and any
surrounding walls. Position the back of your appliances at least 2 in. (5.1
cm) away from the wall. If there’s a door in front of your appliances,
make sure that it is vented properly and at least 3 in. (7.6 cm) from the
front of your appliances.
66.9 in. (170 cm)
2 in. (5.1 cm)
1 in. (2.5 cm)
1 in. (2.5 cm)
23.4 in. (59.5 cm)
3 in. (7.6 cm)
25.7 in. (65.3 cm)
2 in. (5.1 cm)
48 in.² (310 cm²)
24 in.² (155 cm²)
3 in. (7.6 cm)
3 in. (7.6 cm)
Dryer
Washer
