16-Cycle 4.4 Cu. Ft. Front Load Electric Dryer
INSTALLATION INSTRUCTIONS
9 Using the two connecting brackets as guides, use a 3 mm drill bit to drill holes
into the washer to connect the brackets (two holes per bracket). Use the left
bracket on the left side and the right bracket on the right side.
10 Attach the connecting bracket rubber pads to the inside face of the two
connecting brackets.
11 Use the provided screws (one screw per bracket) to attach the connecting
brackets to your dryer. You installed the brackets on the washer in step 9.
Note: There are no pilot screw holes in the washer. You must drill directly into
the washer cover. Make sure that you use a 3 mm drill bit.
Note: The connecting brackets are labeled L (left) and R (right).
