NS-HF2005
STEP 5 - Install the plugs and glass supports.
You’ll need
1 Insert four adjustable glass supports (F) into the holes on the tops of the upper front and back crossbars (2 and 3), two
on each crossbar.
2 Insert eight rubber plugs (G) into the holes in the middle frame (4), four on each side.
3 Insert eight rubber plugs into the holes in the lower frame (5), four on each side.
G Rubber plug
(16)
F Adjustable glass support
(4)
