Insignia NS-LCD47HD-09 Service Manual

47″LCD TV Best Buy NS-LCD47HD-09
53
9.2 Power Board
CN901
SOCKET
87T 501 44 DL
1 2
3
F901
5A/250V
C957
220pF/250V
R903
510K OHM 1/4W
C903
220pF/250V
L903
L
1
2
4
3
L902
L
1 2
4 3
C904
0.047UF
-
+
BD901
D10XB60
2
1
3
4
C958
220pF/250V
L901
L
1
2
4
3
R+
R902
510K OHM 1/4W
C901
1uF/520V
C954
NC
R901
510K OHM 1/4W
RV901
BO
1.0
A
12Monday, March 03, 2008
<
称爹 >
02.ACside
715T2802 F
OEM MODEL Size
Rev
Date
Sheet
of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
t
NR901
NTCR
1 2
HS1: P/NQ90T0124 1
BD901
C902
220pF/250V
65T305K2212E3

Insignia NS-LCD47HD-09 Specifications

General

Screen Size	47 inches
Display Technology	LCD
Aspect Ratio	16:9
HDMI Ports	3
USB Ports	1
Contrast Ratio	3000:1
Brightness	500 cd/m²
Response Time	8 ms
Speakers	2
Viewing Angle	178° (horizontal and vertical)
Inputs	1 x Component, 1 x Composite, 1 x VGA
Audio Output	20W (10W x 2)
