Package contents
Parts
Make sure that you have all the parts necessary to assemble your new monitor mount:
Hardware
Make sure that you have all the hardware necessary to assemble your new monitor mount:
Tools required
Make sure that you have the tools necessary to assemble and install your new monitor mount:
VESA mount patterns
Your monitor mount works with the following VESA screw hole patterns:
• 75 × 75 mm (3 × 3")
• 100 × 100 mm (3.9 × 3.9")
#PARTQTY.#PARTQTY.
1 Tube cover 2 4 Support base 1
2 Monitor support arm 1 5 Base clamp 1
3 Monitor support tube 1 6 Anti-slip rubber pads 2
Note: You may not use all the included hardware.
Cable support brackets
(pre-installed)
A M4 x 12 mm (8) B M5 x 12 mm (8) C M6 x 20 mm (3) D M6 x 10 mm (2) E 6.5 x 13x2 (16)
Phillips screwdriver
(not provided)
F 4 x 4 mm Allen wrench
(provided)
G 5 x 5 mm Allen wrench
(provided)
