28
NS-24ER310NA17/NS-24ER310CA17
NS-32DR310NA17/NS-32DR310CA17/NS-48DR510NA17
www.insigniaproducts.com
48"model
1 Make sure that your TV’s power cord is unplugged and all connected devices are turned off.
2 Connect the incoming cable from the cable wall jack to the cable-in jack on the cable or satellite box.
3 Connect an HDMI® cable (not provided) to an HDMI jack on the side of your TV and to the HDMI OUT jack on the
cable or satellite box.
4 Plug your TV’s power cord into a power outlet, turn on your TV, then turn on the cable or satellite box.
5 On the Home screen, press or to highlight the HDMI 1, HDMI 2, or HDMI 3 tile, then press OK.
Note
If your TV is the 24" or 32" model, go to 24" or 32" model on page 27.
Note
An HDMI® cable carries both audio and video. You do not need to use any
audio cables.
HDMI® cable
Cable or
satellite box
Side of TV
HDMI® cable
connector
HDMI® jack
On your TV
Cable
wall jack
To Next Page
