Part No. 13954 Rev.A
FOODSERVICE DISPOSER
Installation Manual
www.insinkerator.com/foodservice
Please be certain that the person who installs or uses this appliance carefully reads
and understands the Safety Instructions contained in this manual.
The Danger signal indicates an immediately hazardous situation which, if not
avoided, will result in death or serious injury.
The Warning signal alerts you to potential hazards or unsafe practices which,
if not avoided, could result in severe personal injury or death.
The Caution signal alerts you to hazards of unsafe practices which, if not avoided,
may result in minor personal injury or property damage.

Questions and Answers

  • D
    Daniel HatfieldAug 3, 2025
    What to do if my InSinkErator Garbage Disposal won't start and water doesn't flow?
    • J
      Jonathan WilliamsAug 4, 2025
      If your InSinkErator garbage disposal won't start and no water is flowing, it could be due to no incoming water or the electrical disconnect switch being reactivated without waiting for the 30-second delay. Ensure the electrical supply is turned on. Then, wait 30 seconds before attempting to start it again.
  • M
    Maurice ScottAug 11, 2025
    What to do if my InSinkErator Garbage Disposal won't start but water flows?
    • L
      lawrenceheidiAug 11, 2025
      If your InSinkErator garbage disposal won't start but water is flowing, it could be due to the overload protector being tripped or the disposer being jammed. First, turn the control to the off position and press the red reset button on the disposer. If it is jammed, turn the control to the off position, then insert a de-jamming wrench (not supplied) through the sink opening, placing it over the raised bars on the shredder. Twist the wrench back and forth to free the jam, and then remove any foreign materials. Allow the disposer to cool for 3-5 minutes, then press the red reset button. If it still doesn't work, consider contacting an authorized service center.
  • E
    Elizabeth StoneAug 18, 2025
    Why does my InSinkErator SS-200 Garbage Disposal motor stop while grinding?
    • C
      Cynthia PerezAug 18, 2025
      If your InSinkErator garbage disposal motor stops while grinding, but water continues to flow, it's likely due to the disposer being jammed or the overload protector being tripped. If the disposer is jammed, please refer to the instructions for unjamming the disposer. Additionally, turn the control to the off position and press the red reset button on the disposer. Allow the unit to cool for 3-5 minutes before pressing the reset button.
  • L
    Lindsey GarciaAug 26, 2025
    How to fix frequent overload protector trips in my InSinkErator SS-200?
    • J
      jonlopezAug 26, 2025
      If the overload protector in your InSinkErator garbage disposal trips frequently, it's likely because the disposer is overloaded with food waste. To prevent this, avoid overloading the disposer with excessive amounts of food waste.

Summary

Installing the Disposer

Standard InSinkErator Mountings (#5 Assembly)

#5 Mounting Assembly Installation

Step-by-step instructions for installing the #5 sink flange to a standard 3-1/2 to 4 inch sink opening.

Plumbing Connections

Standard Motor Connection Wiring Diagrams

Electrical Connections

Electrical Connection Procedure

Step-by-step guide for connecting the disposer to the electrical supply, including safety precautions.

Operating Instructions

Operating the Disposer

Instructions on how to operate the disposer, including feeding waste and using the control switch.

Safety Warnings for Operation

Crucial safety warnings for operation, including prohibited items, jam clearing, and personal injury risks.

Troubleshooting

Disposer Not Starting or No Water Flow

Diagnoses and solutions for issues where the disposer will not start and water does not flow.

Disposer Not Starting, Water Flowing

Diagnoses and solutions for when the disposer fails to start but water flows.

InSinkErator SS-200 Specifications

General IconGeneral
BrandInSinkErator
ModelSS-200
CategoryGarbage Disposal
