Inspire BL1 User Manual

PARTS & HARDWARE LIST
Part #
Parts Description
Q'ty
Qty Rec'd
Part#
Hardware Description
Q'ty
Qty Rec'd
1
Front Foot Assembly
1
77
Hex Bolt, M12*160
1
2
Base Frame Assembly
1
79
Hex Bolt, M16*230
4
3
Rear Foot Assembly
1
81
Hex Bolt, M10*70
6
4
Shroud Mount Rod, Lower
2
82
Hex Bolt, M12*90
1
5
Shroud Mount Bracket, Upper
1
83
Hex Bolt, M10*60
3
6
Weight Selector Tube
1
85
Hex Bolt, M10*115
1
7
Slider Assembly
1
86
Hex Bolt, M10*100
5
8
Lower Arm
2
87
Hex Bolt, M10*40
2
9
Upper Arm
2
88
Hex Bolt, M12*100
1
10
Upper Main Frame Assembly
1
89
Hex Bolt, M12*80
1
11
Lower Main Frame Assembly
1
90
Button Head Screw, M6*12
4
13
Top Beam Plate
2
93
Button Head Screw, M6*75
1
14
Press Arm Mount
1
94
Button Head Screw, M6*15
2
16
Press Arm Mount Cover Plate
1
97
Button Head Screw, M10*90
4
17
Lat Bar
1
98
Setscrew, M6*8
2
18
Press Arm Assembly
1
99
Flathead Nut, φ17*23*M6
1
20
Backpad Tilt Frame
1
100
Flat Head Nut, φ17*25.5*M6
2
21
Roller Tube
3
102
Flat Head Screw, M10*15
2
22
Pulley Bracket, Cable Tensioner
1
103
Philips Head Screw, M5*12
1
23
Seat Stem
1
106
Cap Screw, M5*10
1
24
Leg Extension Assembly
1
107
Flat washer, Φ10
24
25
Revolving Straight Bar
1
108
Flat washer, Φ12
8
26
Chain
1
111
Flat washer, Φ40*Φ16.5*2.5
8
37
Pulley Assembly, Φ3 1/2"
11
112
Arc Washer, Φ10
16
38L
Shroud, Left
1
116
Lock Nut, M10
19
38R
Shroud, Right
1
117
Lock Nut, M12
4
40
Step Bushing, Φ12 ID
8
118
Lock Nut, M16
4
43
Large Plastic Washer
2
120
Allen Wrench, 3mm
1
44
Foam Roller
6
121
Allen Wrench, 4mm
1
45
Endcap, Roller Tube
6
122
4-Way Po Plug Wrench, 5mm
1
47
Pop-Pin Shaft, 140 long
1
123
Allen Wrench, 6mm
1
50
Lat Bar Holder
2
51
Barrel Spacer, 1" Long
6
52
Spacer Tube, 3" long
1
53
Seat Pad
2
65
Foot Plate Assembly
1
68
Cable Assembly
1
69
Cable Ball
2
70
"U" Bracket, Cable End
2
73
Spring Clip
3
74
Adjustable Bumper
4
PAGE 2

Inspire BL1 Specifications

General

Brand	Inspire
Model	BL1
Category	Home Gym
Language	English
