Inspire M3 User Manual

Seat Stem
Leg Extension
Arm
Plastic Spacer Tube
STEP 39B
Note: Be sure that this
portion of the insert that sticks
out, faces the machine.
2 - Roller Pads with Inserts
2 – Aluminum Endcaps
2 – 1” Flat Head Bolts
.
Assemble Thigh Pads
1 – 2” Hex Bolt in front
1 – 1 ¾” Hex Bolt in Back
2 – 3/8” Flat Washers
4 - Roller Pads
4 – Large Plastic Washers
4 – Aluminum Endcaps Roller Tubes
4 - 1” Flat Head Bolts
Step 38: Insert Seat Stem into Seat Base Frame, One (3/8” x 2” Hex Bolt) In Front
then attach Seat Pad to Seat Stem using: One (3/8” x 1 ¾” Hex Bolt) In Back
Two (3/8” Flat Washers)
NOTE: Wrench tighten now, do not over tighten.
Step 39A: Slide two Spacer Tubes and two Large Plastic Washers onto front Roller Tube,
followed by Roller Pads. Slide two Large Plastic Washers onto Backpad Roller Tube,
followed by Roller Pads. Secure Roller Pads with Aluminum Endcaps and 1” Flat Head
Bolts.
Step 39B: Slide two Roller Pads with Insert onto Leg Extension Roller Tube. Secure Roller Pads
with Aluminum Endcaps and 1” Flat Head Bolts.
NOTE: Wrench Tighten All Flat Head Bolts with the supplied 6mm Allen Wrench.
Step 40: Slide Thigh Pads onto Seat Stem as shown in diagram. Secure with Velcro.
Page 24
STEP 38
STEP 39A
STEP 40

Inspire M3 Specifications

General

Resistance Type	Weight Stack
Weight Capacity	300 lbs
Color	Black
Frame	Steel
Finish	Powder coat
Material	Steel
Included Accessories	Lat Bar
Exercises	Chest Press, Incline Press, Decline Press, Lat Pulldown, Seated Row, Leg Extension, Leg Curl, Preacher Curl, Ab Crunch
Press Arm	Adjustable
