Insta 228 - Page 15

120V AC 230V AC
68
BRACKET, STRAIN RELIEF CORD MPSS163 MPSS163
69
STRAIN, RELIEF MPSS168 MPSS168
70
SCREW, PHILLIP PAN HEAD 10-32 x 0.375 LONG MHSP103238S MHSP103238S
71
POWER CORD (USA MODEL) MPPW141 MPPW142
71A POWER CORD (EUROPEAN MODEL) N/A MPPW202
71B POWER CORD (UK MODEL) N/A MPPW203
72
WIRE HARNESS MPW90320 MPW90320
75
POST, ARM MPSP235 MPSP235
78
INSULATION, MICRO SWITCH MH700214 MH700214
79
WIRE, HEATER MPPW700 MPPW700
82
WASHER, CUT 5/16 I.D. MHWC516 MHWC516
83
STOP PLATE, REAR POST MPSP2303 MPSP2303
87
SCREW, SOCKET HD 1/4-20 x 4.0 LONG MHSSH14204 MHSSH14204
89
CLEVIS MPSP221 MPSP221
90
SCREW, HEX BOLT 1/4-20 x 1 IN LONG MHBH14201S MHBH14201S
91
SCREW, SOCKET SET 5/16-18 x 0.25 IN MHSST5161814 MHSST5161814
92
NUT, HEX 6-32 MHNH632 MHNH632
93
WASHER, SHIM #6 (.031) MH311150019 MH311150019
94
SPACER, LONG NYLON 0.166 id X 1/4 IN MH110969111 MH110969111
95
PLATE, CONTROLLER MPP90011 MPP90011
96
SCREW, PHILLIP PAN HEAD 8-32 x 0.25 IN MHSP83214 MHSP83214
97
SCREW, PHILLIP PAN HEAD 8-32 x 0.5 IN MHSP83212 MHSP83212
100
SCREW, PHILLIP PAN HEAD 8-32 x 1.0 IN MHSP8321 MHSP8321
101
WASHER, #8 MHWSAE8 MHWSAE8
102
WASHER LOCKE INT #8 MHWLIT8 MHWLIT8
103
NUT, HEX 8-32 MHNH832 MHNH832
106
BUSHING, GUIDE POST MPSB070 MPSB070
107
FITTING, GREASE (LONG) MPSF144 MPSF144
109
WASHER, WAVE 0.5 IN MH5806282 MH5806282
110
SCREW, SET 8-32 x 0.1875 IN LONG MHSST832316 MHSST832316
111
GROUND WIRE MPW90125 MPW90125
112
SCREW, PHILLIP PAN HEAD 6-32 x 0.25 IN MHSP63214 MHSP63214
113
LUG PIN MPP0139 MPP0139
115
LABEL, ROHS / WEE MPL90175 MPL90175
A1
PLATEN, HEAT ASSY MPP228A1A MPP228A2A
A2
LUG PIN ASS'Y MPP90141 MPP90141
A3
HANDLE, PRESSURE ASS'Y MPSH515 MPSH515
A4
PLATEN, LOWER ASSY MASP007 MASP007
A5
CAM/PRESSURE LEVER ASSY MPSC201 MPSC201
A6
BASE ASSY MPSB204A MPSB204A
P/N
PART NAME
MODEL VOLTAGE
MODEL 228 0721
