Insta 228 - Installation; Degree of Protection; Specifications

FOR USE BY QUALIFIED PERSONNEL ONLY
Installation
DOMESTIC
Use a separate 15 amp AC circuit.
Only industrial extension cords with
proper wire size should be used: size
16/3 wire for distances up to 25 feet,
and size 14/3 for distances up to 50
feet.
INTERNATIONAL
Use a designated 16 amp AC circuit.
Only industrial extension cords with
proper wire size (2.5 sq. mm) shall be
used.
IMPORTANT
The appliance must be plugged into a
proper receptacle of the proper size
and rating. Equally important the line
voltage must be able to accommodate
this appliance as well as other
appliances operating on this circuit.
Specifications
MODEL 228
Voltage 120 Volts AC 50/60 Hertz
Model 228 1750 Watts 14.6 Amps
Voltage 230 Volts
AC 50/60 Hertz
Model 228 2200 Watts 9.6 Amps
Model 228
Machine Weight 94 Pounds (42.6 KG)
Degree of Protection
IP (Ingress Protection) rating according to IEC
60529.
NOTE
IEC 60529 does not specify sealing
effectiveness against the following:
mechanical damage of the equipment;
the risk of explosion; certain types of
liquid conditions, e.g. those that are
produced by condensation; corrosive
vapours; funus; vermin
IP54=IP
1
st
Digit5
2
nd
Digit4
1
st
Digit
Protection from
solid objects
2
nd
Digit
Protection from
moisture
0 Non protected 0 Non protected
1
Objects greater
than 50mm
1 Dripping water
2
Objects greater
than 12mm
2
Dripping water
when tilted up to
15 deg.
3
Objects greater
than 2.5mm
3 Spraying water
4
Objects greater
than 1mm
4 Splashing water
5 Dust protected 5 Water jets
6 Dust tight 6 Heavy seas
-- --- 7
.15m – 1m
immersion
-- --- 8 1m + submersion
