Insta360 ONE RS Quick Start Guide

Swipe down
Open the Shortcut menu: Adjust screen brightness ( ),
touch screen on / off (
/
), LED on / off ( / ),
grid ( / ), settings
(
), etc.
* Start Shooting: After you've selected mode and settings, just hit the shutter
button once to start a recording, and then again to stop.
EN
7
Tap the icon Q,
Select preset capture modes.
Tap the icon ,
Zoom in or out.
Swipe up
Access media gallery.
Swipe left/right from the center
Select capture mode.
Tap the parameters at the bottom
Set resolution and framerate settings.

Insta360 ONE RS Specifications

General

Bluetooth	Yes
Product color	Black
ISO sensitivity	100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2200, 2250, 2500, 3200
Wi-Fi frequency	5 GHz
Camera interface	USB Type-C
Bluetooth version	5.0
Fixed focal length	6.52 mm
Maximum aperture number	2.2
Operating temperature (T-T)	-20 - 40 °C
Fastest camera shutter speed	1/8000 s
International Protection (IP) code	IPX3
HD type	-
Video resolutions	3840 x 1920 pixels
Maximum frame rate	50 fps
Video formats supported	INSV
Maximum video resolution	6144 x 3072 pixels
Image formats supported	INSP, RAW
Maximum image resolution	6528 x 3264 pixels
Storage media	Memory card
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	1000 GB
Audio formats supported	AAC
Virtual Reality (VR) ready	No
Power source	Battery
Battery capacity	1350 mAh
Battery life (max)	1 h
Mobile operating systems supported	Android, iOS

Weight and Dimensions

Depth	129.3 mm
Width	53.2 mm
Height	49.5 mm
Weight	239 g
