Insta360 ONE RS Quick Start Guide

4 Know Your Insta360 ONE RS
Power On / Off
When the camera is turned off, press the Power Button to power it on.
In standby mode, press the Power Button to light off / on the touch screen.
In standby mode, long press the Power Button for 2 seconds to power it off.
Using the Touch Screen
Note: When using ONE RS in water, please lock the touch screen ( )
to avoid accidental presses. After locking the touch screen, you can use the
Power Button to change modes.
EN
6
Note: The button cover on the Mounting Bracket can
be disassembled. If the cover or windproof foam is
damaged, it can be removed and replaced. When
reinstalling, the buttons should be aligned as in the
picture. (Please contact Insta360's official customer
service team for replacement of this part.)

Insta360 ONE RS Specifications

General

Bluetooth	Yes
Product color	Black
ISO sensitivity	100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2200, 2250, 2500, 3200
Wi-Fi frequency	5 GHz
Camera interface	USB Type-C
Bluetooth version	5.0
Fixed focal length	6.52 mm
Maximum aperture number	2.2
Operating temperature (T-T)	-20 - 40 °C
Fastest camera shutter speed	1/8000 s
International Protection (IP) code	IPX3
HD type	-
Video resolutions	3840 x 1920 pixels
Maximum frame rate	50 fps
Video formats supported	INSV
Maximum video resolution	6144 x 3072 pixels
Image formats supported	INSP, RAW
Maximum image resolution	6528 x 3264 pixels
Storage media	Memory card
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	1000 GB
Audio formats supported	AAC
Virtual Reality (VR) ready	No
Power source	Battery
Battery capacity	1350 mAh
Battery life (max)	1 h
Mobile operating systems supported	Android, iOS

Weight and Dimensions

Depth	129.3 mm
Width	53.2 mm
Height	49.5 mm
Weight	239 g
