InStep Robin - Remove the Wheels

21 InStep Robin Trailer
❷ Remove the wheels by:
a. Sliding the safety loop from the end of the locking pin.
b. Remove the locking pin from the axle, and pull the
wheel out of the hole in the frame bracket.
c. Slide the locking pin back into the frame hole
❸ Remove the locking pin from the tow bar bracket. Figure 6.4
❶ Remove the ag pole and separate the ag pole secons.
Figure 6.3
1
Figure 6.3
2
3
Figure 6.4
