15 InStep Robin Trailer
ATTACHING TO A BICYCLE WITH QUICK RELEASE AXLES
❶ Flip the quick release lever and remove the nut and spring
from the opposite side. Figure 4.9
❷ Remove the axle skewer and spring. Leave the wheel in place.
Figure 4.10
❸ Slide the axle skewer through the coupler plate and tab
washer. Figure 4.11
The hook on the
tab washer must
face towards the
wheel hub
The bell of the
coupler plate must
face out
The wide end of
the spring must
face out, touching
the lever
1
2
Figure 4.9
Figure 4.10
Figure 4.11
3
