InStep Robin User Manual

InStep Robin Trailer 22
❼ Carefully fold the trailer side walls down. Figure 6.7
❽ Press the locking spring pins down and push the side rails in.
Figure 6.7
Note: Coupler
plate will remain
assembled to bike
99% of the me
❹ Fold the tow bar underneath the trailer. Figure 6.5
❺ Place the locking pin back through the tow bar and bracket
Figure 6.5
❻ Unsnap the back panel, remove the crossbar fabric, and press
the crossbar release buon. Rotate the crossbar down into the
trailer interior. Figure 6.6
❾ Place any loose items such as the canopy and wheels inside the
passenger compartment.
❿ Store in a dry place. Important! If the storage area is hot then
release the some air from the res. This will help prevent
excessive expansion or popping.
5
4
6
Figure 6.5
Figure 6.6
Figure 6.7
Unsnap
Side rail Side rail
Locking
spring pin

InStep Robin Specifications

General

Brand	InStep
Model	Robin
Category	Bicycle Accessories
Language	English
