Chapter: Lifting and handling
62 M10-17419-EN
Ensuring that the sling extends vertically from the front of the crosshead minimizes
the risk of damage to the top plate. When the frame is lifted, it will tilt toward the rear.
Crush hazard - Ensure that all persons in the immediate area are standing away from
the frame during lifting.
Do not lift the frame more than 8 cm (3 in) off the floor.
2. Slowly and carefully lift the frame off the floor.
3. Remove the shipping skid, if it has not already been removed.
4. Move the frame to its operating location.
5. Place the load frame carefully into position.
6. Remove the lifting straps from the crosshead, and any protective padding, if used.
When the frame is in its operating location, you can proceed with the installation
process.
