Integra Codman 901001ESUO User Manual

EN - ENGLISH
15
Classification
Mains Supply 100-240 VAC ; 50/60 Hz
Power Consumption Without HF output: approximately 50 VA
At maximum output power: approximately 500 VA
Protection Class I
LF and RF Leakage Currents According to IEC 60601-2-2
Application Type CF; defibrillator safe
Operating Mode Intermient 10 seconds ON /30 seconds OFF
Mains Fuse 2 x T 3.15 AH 250 V 5x20 mm
Signal Level RF indicator: 40-65 dB(A) adjustable. Alarm: 65 dB(A)
Weight Approximately 5.0 kg
Dimensions Width 403 mm
Height 170 mm
Depth 313 mm
Standards IEC 60601-1:2005 + A1:2012, Ed. 3.1
CAN/CSA-C22.2 No. 60601-1:14
ANSI/AAMI ES60601-1:2005/(R)2012 and A1:2012, C1:2009/(R)2012 and A2:2010/(R)2012
IEC 60601-1-2:2007, Ed. 3.0
IEC 60601-1-2:2014, Ed. 4.0
IEC 60601-2-2:2017, Ed. 6.0
TECHNICAL SPECIFICATIONS AND ENVIRONMENTAL REQUIREMENTS
Current Mode Current Type RF Output Power RF Output
Current
RF Output
Voltage
Nominal Modulation
MONOPOLAR
MONOCUT (Cuing) max. 80 W ±20 % on 600  0.51 A on 600  max 800 Vp 4.00 MHz 33 kHz
MONOCOAG (Coag.) max. 80 W ±20 % on 400  0.51 A on 400  max  Vp 4.00 MHz 33 kHz
BIPOLAR
BICUT (cuing) max. 80 W ±20 % on 300  0.6 A on 300  max 400 Vp 4.00 MHz 33 kHz
BICOAG (coag.) max. 60 W ±20 % on 50  1.2 A on 50  max 440 Vp 4.00 MHz 33 kHz
Environmental Operational Transport Storage
Temperature 10° to 40°C / 50° to 104°F -40° to 60°C / -40° to 140°F -40° to 60°C / -40° to 140°F
Relative Humidity
(non-condensing)
30% to 75% 15% to 85% 15% to 85%
Atmospheric Pressure 700 hPa to 1050 hPa 500 hPa to 1050 hPa 500 hPa to 1050 hPa
