COAGCUT
Codman® Electrosurgical Generator
BICOAGBICUTMONOCUT
Monopolar Bipolar
MONOCOAG
CONTROLS, INDICATORS & CONNECTIONS
Front Panel
Watt
max.
Watt
max.
1. Power Buon
This buon controls the primary AC power to the Generator. When the Generator is ON, the Display Screen, Operating
Mode Buons and Power Buon illuminate.
2. CUT Output Power Seing Knob
Turning the output power seing knob clockwise increases the power seing and turning it counterclockwise decreases
the power seing of the Generator. The seing is visible on the CUT Display Screen.
3. CUT Display Screen
The screen shows the output power seing for CUT (MONOCUT or BICUT, depending on which Operating Mode Buon is
activated).
4. CUT Indicator Light
The light is illuminated when the user activates the CUT mode, either by finger switch or Foot Pedal.
5. Operating Mode Buons
These buons control the operating mode of the Generator. The Display Screen will show the output power seing for the
selected Operating Mode. Only one (1) CUT and one (1) COAG mode can be selected simultaneously.
- MONOCUT
- BICUT
- MONOCOAG
- BICOAG
6. COAG Indicator Light
The light is illuminated when the user activates the COAG mode, either by finger switch or Foot Pedal.
1
9 10 11 12
2
3 4 5
6
7
8
