118/119 PAGE
DHC-40.2
PC BOARD PARTS LIS
U008 U0080 BAHDM-0290-1A * 1 1B234590-1A
U0080 FRONT HDMI TERMINAL PC BOARD AS BAHDM-0290-1A 1 1B2345290-1A
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D8661 C-DIODE KDS4148U 1 223283R2
D8661 or C-DIODE 1SS352 ( 1) 223234R2
D8662 C-DIODE KDS4148U 1 223283R2
D8662 or C-DIODE 1SS352 ( 1) 223234R2
Q8661 IC TMDS141RHARG4 1 22242586R2
[TRANS COIL]
L8661 CORE BLM18PG181SN1D 1 2350005R1
[CAPACITOR]
C8661 C-FILM C ECHU16V-104J 1 373041044R2
C8663 C-CERA C CK725F1A-105Z1 1 332181050R1
C8664 C-CERA C CK725B1H-102K1 1 332101025R1
C8669 C-CERA C CK725F1A-105Z1 1 332181050R1
C8670 C-CERA C CK725B1H-102K1 1 332101025R1
C8671 C-CERA C CK725F1A-105Z1 1 332181050R1
C8672 C-CERA C CK725B1H-102K1 1 332101025R1
C8673 C-CERA C CK725F1A-105Z1 1 332181050R1
C8674 C-CERA C CK725B1H-102K1 1 332101025R1
C8675 C-CERA C CK725F1A-105Z1 1 332181050R1
C8676 C-CERA C CK725B1H-102K1 1 332101025R1
C8677 C-CERA C CK725B0J-106K 1 332091065R2
C8680 C-CERA C CK725B0J-106K 1 332091065R2
[RESISTOR]
R8667 C-CARBON R RN72K1J-473JE 1 435034734R1
R8668 C-CARBON R RN72K1J-473JE 1 435034734R1
