Integra DHC-40.2 Service Manual

6/119 PAGE
A991 or BATTERY R6/AA(UM-3) ( 2) 3010054
A992 MIC MIC-7000 1 245044
A993 ANT COIL NMA-3057 1 232140
A994 FM ANT AS Type W 1 292191
DHC-40.2
PC BOARD PARTS LIS
T
U003 U0031, 3, 4 BATRM-0450-1C * 1 1B248550-1C N
U0031 SPEAKER TERMINAL_2 PC BOARD AS BATRM-0451-1C 1 1B2485451-1C N
U0033 CONNECTOR PC BOARD AS BATRM-0453-1C 1 1B2485453-1C N
U0034 POWER SUPPLY PC BOARD AS BAPS-0454-1C 1 1B2485454-1C N
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D911 DIODE 1SS133 1 223163T
D912 DIODE 1SS133 1 223163T
D921 DIODE 1SS133 1 223163T
D922 DIODE 1SS133 1 223163T
D923 DIODE 1SS133 1 223163T
D924 DIODE 1SS133 1 223163T
D925 DIODE 1SS133 1 223163T
D926 DIODE 1SS133 1 223163T
D930 DIODE 1SS133 1 223163T
D9300 DIODE D3SBA20 1 22380271F
D9300 or DIODE RBV402 ( 1) 22380022F
D9301 ZENER D MTZJ15B 1 224471502T
D9302 ZENER D MTZJ15B 1 224471502T
D9303 DIODE 1SS133 1 223163T
D9304 DIODE 1SS133 1 223163T
D931 DIODE 1SS133 1 223163T
D933 DIODE 1SS133 1 223163T
D934 ZENER D MTZJ3.6B 1 224470362T
