Integra DHC-80.2B - Page 116

56/157 PAGE
RL4005 RELAY NRL-2P2A-DC12-178 1 25065664
RL4006 RELAY NRL-2P2A-DC12-178 1 25065664
RL4008 RELAY NRL-2P2A-DC12-178 1 25065664
RL4009 RELAY NRL-2P2A-DC12-178 1 25065664
[TUNER UNIT]
U2700 REMO SENS KSM-603TE2Q 1 24130018 <B MDD, MMA>
U005 U0050 ~ U0057 BADG-0208-1N *
1
1B234508-1N
<B MDD>
U0050 DAC PC BOARD AS BADG-0208-1N
1
1B2345208-1N
<B MDD>
U0051 MICROPROCESSOR PC BOARD AS BACPU-0209-1N
1
1B2345209-1N
N <B MDD>
U0052 ZONE-2 VOLUME PC BOARD AS BAAR-0210-1N
1
1B2345210-1N
N <B MDD>
U0053 EQUALIZER AMP PC BOARD AS BAAF-0211-1N
1
1B2345211-1N
N <B MDD>
U0054 BUFFER AMP PC BOARD AS BAACC-0212-1N
1
1B2345212-1N
N <B MDD>
U0055 SIRIUS PC BOARD AS BARF-0204-1N
1
1B2345204-1N
N <B MDD>
U0056 DIGITAL INPUT PC BOARD AS BAETC-0246-1N
1
1B2345246-1N
N <B MDD>
U0057 D-SUB15 PC BOARD AS BAETC-0247-1N
1
1B2345247-1N
<B MDD>
U005 U0050 ~ U0057 BADG-0208-1P *
1
1B234508-1P
<B MMA>
U0050 DAC PC BOARD AS BADG-0208-1P
1
1B2345208-1P
<B MMA>
U0051 MICROPROCESSOR PC BOARD AS BACPU-0209-1P
1
1B2345209-1P
N <B MMA>
U0052 ZONE-2 VOLUME PC BOARD AS BAAR-0210-1P
1
1B2345210-1P
N <B MMA>
U0053 EQUALIZER AMP PC BOARD AS BAAF-0211-1P
1
1B2345211-1P
N <B MMA>
U0054 BUFFER AMP PC BOARD AS BAACC-0212-1P
1
1B2345212-1P
N <B MMA>
U0055 SIRIUS PC BOARD AS BARF-0204-1P
1
1B2345204-1P
N <B MMA>
U0056 DIGITAL INPUT PC BOARD AS BAETC-0246-1P
1
1B2345246-1P
N <B MMA>
U0057 D-SUB15 PC BOARD AS BAETC-0247-1P
1
1B2345247-1P
<B MMA>
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D4001 ZENER D UDZS5.6B 1 224550560R2
D4001 or ZENER D MAZ8056-M ( 1) 224750562R2
D4002 ZENER D UDZS5.6B 1 224550560R2
D4002 or ZENER D MAZ8056-M ( 1) 224750562R2
D4003 ZENER D UDZS3.6B 1 224550360R2 <B MDD, B MMA>
D4004 ZENER D UDZS3.6B 1 224550360R2
D7002 C-DIODE 1SS352 1 223234R2
D7002 or C-DIODE 1SS355 ( 1) 223269R2
D7002 or C-DIODE MA2J111 ( 1) 223279R2
