P4009B SOCKET NSCT-15P2108 1 25052211
P4020B SOCKET 9210B-1-13Z140-PT1 1 25053364 N
P4021B SOCKET 9210B-1-13Z140-PT1 1 25053364 N
P6851A PLUG IMSA-9142B-26A 1 25056603
P6853A SOCKET NSCT-9P2189 1 25052292
P7003B SOCKET IMSA-9618S-09A 1 25053334R2
P7009B SOCKET IMSA-9142S-18A 1 25053231
P7010B SOCKET IMSA-9142S-26A 1 25053235
P7012 TRM-423(SCREW) NEJITANSI ST3 1 25060495
P7501A PLUG A2545WR2-2x20P(IDE40SIDE) 1 25056643
P8 SOCKET 2MJ-3516-002 1 25053355 <B MDD>
P8000 SOCKET MDS-15P-V02(DSUB15) 1 25053362 <B MDD, B MMA>
P8002A SOCKET NSCT-11P2402 1 25052505 <B MDD, B MMA>
S3701 SLIDE SW SSSS213000 1 25060497
S7000 SLIDE SW SSSS213000 1 25060497 <B MDD, B MMA>
[TUNER UNIT]
U3884 PHT CP JSR1165-001recieving 1 24120143
U3885 PHT CP JSR1165-001recieving 1 24120143
U3886 PHT CP JSR1165-001recieving 1 24120143 <B MDD, B MMA>
U006 U0060 ~ U0067 BADIS-0121-1C *
1
1B234521-1C
U0060 DISPLAY PC BOARD AS BADIS-0121-1C
1
1B2345121-1C
U0061 LED-SW PC BOARD AS BASW-0122-1C
1
1B2345122-1C
U0062 PHONE JACK PC BOARD AS BAETC-0123-1C
1
1B2345123-1C
U0063 FRONT OPT IN PC BOARD AS BAETC-0124-1C
1
1B2345124-1C
U0064 VOLUME PC BOARD AS BAETC-0125-1C
1
1B2345125-1C
U0065 POWER SUPPLY (SEC) PC BOARD AS BAPS-0126-1C
1
1B2345126-1C
U0066 HOLDER(U0063) PC BOARD AS BAETC-0127-1C
1
1B2345127-1C
U0067 HOLDER(U0101) PC BOARD AS BAETC-0128-1C
1
1B2345128-1C
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D7500 ZENER D UDZS10B 1 224551000R2
D7520 C-DIODE 1SS355 1 223269R2
D7520 or C-DIODE 1SS352 ( 1) 223234R2
D7520 or C-DIODE MA2J111 ( 1) 223279R2
D7520 or C-DIODE KDS4148U ( 1) 223283R2
