DEBUG MODE-1
TX-SR876/SA876
<Ex.>
E = UNLOCK
= LOCK
DIR Input Lock
1
0 = None
1 = COAX1
2 = COAX2
3 = COAX3
4 = OPT 1
5 = OPT 2
7 = OPT(FRONT)
8 = HDMI1
9 = HDMI2
A = HDMI3
B = HDMI4
C = NET(Not Used)
DIR Input RX
2
32K
= 32 kHz without Emphasis
44K
= 44.1 kHz without Emphasis
48K
= 48kHz without Emphasis
64K
= 64 kHz
Sampling Frequency
and Emphasis
-
4
6
To set in DSP DEBUG MODE
1. Press and hold down
DISPLAY button, then press
ON/STANDBY
button while the unit is powered on.
The version number of main microprocessor will be displayed only for 3 seconds.
3. Press
DISPLAY
button while
the 1st DSP version
is displayed. The status of DSP and related IC will be displayed.
D = Digital(SPDIF)
A
= Analog
M = Anolog Multich
p = PCM Fixed
d
= DTS Fixed
I = Digital(I2S_1)
= Digital(I2S_4)
= Digital(DSD)
S
d
DIR/ADC
3
Content of display
1
4
2
5
6
8
7
10
3
9
11
12
13
14
15 18
16
19
20
22
21
24
17
23
25 26
27
28
<Ex.>
6 = OPT 3(Not Used)
88K
= 88.2 kHz
96K
= 96 kHz
176
= 176.4 kHz
192
= 192 kHz
32e
= 32 kHz with Emphasis
44e
= 44.1 kHz with Emphasis
48e
= 48 kHz with Emphasis
2. Press TONE+ button within 3 seconds above, the version number of 1st DSP will be displayed.
<Ex.>
Main:
87 1.02/08X23A
DSP 1st:
SR9061:08320A
E5A48K0N/0FFPo
FFFFFF0 0 000
0 = Analog
1 = PCM
2 = Not PCM
3 = Data
4 = DTS CD (Not used)
5 = Multich
6 = Not Decided
DIR Detect Type
7
The status of DSP and related IC is able to be checked by the information displayed on FL as follows.
This information is useful to find the cause of trouble.
4. Press
ON/STANDBY
button to finish.
